Juniper Networks Contrail Networking, developed in the OpenContrail open source project, has long been a part of Red Hat’s millinery. The partnership between Juniper and Red Hat goes back some years now. Collaborating on OpenStack cloud and NFV infrastructure has won these partners success in supporting large enterprises and communications service providers like Orange Business Services.
At the long list of open source festivities in Boston over the next 2 weeks, you will hear these partners in cloud building on their past successful OpenStack + Contrail integration and now putting the spotlight on new integrations to support cloud native. You’ve heard me blog about the OpenContrail integration with OpenShift back a year already (in its first alpha form that I demoed), and more recently for CloudNativeCon and DockerCon talking about how we evolved that work to make this integration enterprise-ready and up-to-date with all the innovation that’s happened in the fast-paced OpenShift releases.
But how do you get the best of OpenStack and OpenShift?
Red Hat has been helping customers to move faster with devops, continuous delivery, and containers using OpenShift for a long time. Naturally Red Hat often does this atop of Red Hat OpenStack Platform, where OpenStack creates clusters of virtual machine hosts for the Red Hat OpenShift Container Platform cluster.
One latent hitch in this double stack is the software-defined networking (SDN). Like OpenStack, OpenShift and Kubernetes (on which OpenShift is based) have their opportunities for improvement. One area that is frequently fortified and improved is the software-defined networking (SDN), and the importance of doing this doubles when you’re running the double stack of OpenShift on top of OpenStack.
Why can SDN be such a snag? Well, the network is a critical part of any cloud, and especially cloud-native, infrastructure because of the enormous volume of microservice-generated east-west traffic, along with load balancing, multi-tenancy, and security requirements; that’s just for starters. The good-enough SDN that is included but swappable in such open source cloud stacks is very often indeed good enough for small cloud setups, but it is common to see the SDN replaced with something more robust for clouds with more than 100 nodes or other advanced use cases like NFV.
Fast and Furious Clouds
I think of this 100-node edge like the 100mph edge of a car… As I make my way to Boston, I just took an Uber to SFO, and of course it was a Prius. Like most cars nowadays they’re very efficient, and great for A-to-B commuting. But also like most cars, when you approach or (hopefully don’t) pass 100mph mark, the thing feels like it is going to disintegrate! I was a little uneasy today flying down the 101 at just 80-something mph. Eeek!
Now I love to drive, and drive fast, but I don’t do it in a bloody Prius! My speed-seeking readers will probably know, as I do, that if you go fast in a sportscar, it is a way better experience. It’s smooth at high speeds, and the power feels awesome. Now let’s say you also aren’t just driving in a straight line, but you’re on the Laguna Seca Raceway. To handle cornering agility, gas and maintenance pit stops, and defense/offense versus the other drivers, you need more than just smooth handling. The requirements add up. I think you get my drift…
My point is that, similarly, if you’re going to build a cloud, you need to consider that you’re going to need a lot more than good enough. Good enough might do you fine for some dev/test or basic scenarios, but if you need performance, elastic scale, resilience, F1-pit-crew speed and ease of maintenance, and a security defense/offense, then you need to invest in building the best. Juniper has been helping its customers build the best networks for over 20 years. It’s what Juniper is known for: high-performance and innovation. When you (or say NSS) compare security solutions, again, Juniper is on top for performance, effectivity (stopping the bad stuff) and value I might add.
When Compounding Good-enough Isn’t Great
Imagine the challenges you can run into with good-enough networking… now imagine you stack two such solutions on top of each other. That’s what happens with OpenShift or Kubernetes on top of OpenStack.
In this kind of scenario, compounding the two stacks’ SDN, as you demand more from your cloud, you will double complexity and twice as quickly hit network disintegration!
Ludacris Mode for Your Cloud
If you want to drive your cloud fast and furious, and not crash, you need some racing readiness. OpenContrail is designed for this, and proven in some of the largest most-demanding clouds. No need to recount the awesomeness here. It’s already well documented. Before you green-light it though, there is one thing we’ve needed to iron out: How does an OpenContrail double stack drive?
When OpenContrail developers were in their first throws of SDN integration for Kubernetes and OpenShift, we often ran it inside of an OpenStack cloud. And what was the OpenStack SDN? OpenContrail of course. Yep, that’s right we have OpenContrail providing an IP overlay on top of the physical network for the OpenStack VM connectivity, and then inside of that overlay and those VMs we installed OpenShift (or Kubernetes) with another OpenContrail overlay. It turns out this SDN inception works just fine. There’s nothing special to it. OpenContrail just requires an IP network, and the OpenStack-level OpenContrail fits the bill perfectly.
In fact, SDN inception is pretty common, but not usually with the same SDN at both levels. The main place this happens in practice is because we run cloud-native CaaS/PaaS stacks like Kubernetes, Mesos, OpenShift paired with OpenContrail on top of public clouds, and that public IaaS line AWS has its own underlying SDN. It provides the IP underlay that we need in those cases.
What about when we control the SDN at the IaaS AND the CaaS/PaaS layers? Even if 2 SDNs (the same or different solution) work well stacked atop each other, it’s not ideal because there is still double the complexity of managing them. If only there was a better way…
A New Hat Stack Trick
This is where the OpenContrail community was inspired to raise the bar, and the Red Hat stack of OpenShift on OpenStack is the perfect motivation. What’s now possible today is to unwind the SDN inception and use one single control and data plane for OpenShift or Kubernetes on top of OpenStack when you run OpenContrail. The way this is realized is by having the OpenStack layer work as usual, and using OpenContrail in a different way with OpenShift or Kubernetes. In that instance, the OpenContrail plugin for OpenShift/Kubernetes master will speak directly to the OpenContrail controller used at the OpenStack layer. To collapse the data plane, we have a CNI plugin passthru that will not require the OpenContrail vRouter to sit inside the host VM for each OpenShift/Kubernetes minion (compute) node. Instead the traffic will be channeled from the container to the underlying vRouter that is sitting on the OpenStack nova compute node. We’ll save further technicalities and performance boost analysis for an OpenContrail engineering blog another day.
Juniper and Red Hat work on this latest innovation of flattening the SDN stack is coming to fruition. It is available today in the OpenContrail community or Juniper Contrail Networking beta, and slated for Juniper’s next Contrail release. As to that, stay tuned. As to catching this in action, visit Juniper and Red Hat at the Red Hat Summit this week and the OpenStack Summit next week. We’ll see you there, and I hope you hear about this and more OpenContrail community innovations ahead and in deployment at the OCUG next week.
